KIOXIA XG8 Series (M.2)
Client NVMe™ SSD
KIOXIA XG8 Series utilizes KIOXIA latest 112-layer, 3D TLC (3-bit-per-cell) flash memory. With 5th generation BiCS FLASH™ and SLC cache features, the XG8 Series SSDs reach up to sequential read/write speeds of 7,000 MB/s and 5,800 MB/s respectively and deliver up to 900K random read and 620K random write IOPS. The power consumption of the XG8 Series is 8.1 W or less in active mode and less than 3 mW in stand-by mode.
The new XG8 Series is optimized for power-sensitive mobile PCs.
Available in a compact M.2 Type 2280 form factor, the XG8 Series comes in four capacity models of 512 GB, 1,024 GB, 2,048 GB and 4,096 GB, each with the option of a Self-Encrypting Drive (SED) model supporting TCG Opal Version 2.01.
Documents
Key Features
- KIOXIA 112-Layer BiCS FLASH™
- PCIe® 4.0, NVMe™1.4
- Capacities up to 4,096 GB
- M.2 Type 2280 Single-sided (512 GB, 1,024 GB, 2,048 GB) / Double-sided(4,096 GB)
- TCG Opal 2.01 Optional for SED
Key Applications
- Thin performance notebook PCs
- High-performance desktop PCs
- Gaming PCs
Specifications
* 表格可以水平滚动。
Base Model Number | KXG80ZN84T09 | KXG80ZNV2T04 | KXG80ZNV1T02 | KXG80ZNV512G |
---|---|---|---|---|
SED Model Number | KXG8AZN84T09 | KXG8AZNV2T04 | KXG8AZNV1T02 | KXG8AZNV512G |
Capacity | 4,096 GB | 2,048 GB | 1,024 GB | 512 GB |
Basic Specifications | ||||
Form Factor | M.2 2280-D2 Double-sided | M.2 2280-S2 Single-sided | ||
lnterface | PCIe® 4.0, NVMe™ 1.4 | |||
Maximum Interface Speed | 64 GT/s (PCIe® Gen4 x4) | |||
Flash Memory Type | BiCS FLASH™ TLC | |||
Performance (Up to) | ||||
Sequential Read | 7,000 MB/s | |||
Sequential Write | 5,800 MB/s | 5,600 MB/s | 5,000 MB/s | |
Random Read | 900K IOPS | 750K IOPS | ||
Random Write | 620K IOPS | 600K IOPS | ||
Power Requirements | ||||
Supply Voltage | 3.3 V ± 5 % | |||
Power Consumption (Active) | 8.1 W typ. | 7.7 W typ. | ||
Power Consumption (L1.2 mode) | 3.0 mW typ. | |||
Reliability | ||||
MTTF | 1,500,000 hours | |||
TBW | 2,400 | 1,200 | 600 | 300 |
Dimensions | ||||
Thickness | 3.58 mm Max | 2.23 mm Max | ||
Width | 22.0 mm ± 0.15 mm | |||
Length | 80.0 mm ± 0.15 mm | |||
Weight | 8.3 g Max | 7.1 g Max | 6.8 g Max | 6.6 g Max |
Environmental | ||||
Temperature (Operating) | 0 ℃ to 95 ℃ (Controller Temperature) | |||
Temperature (Operating) | 0 ℃ to 85 ℃ (Other Components Temperature) | |||
Temperature (Non-operating) | -40 ℃ to 85 ℃ | |||
Humidity (Operating) | 0 % to 90 % R.H. | |||
Vibration (Operating) | 196 m/s2 { 20 Grms } ( 20 Hz to 2,000 Hz ) | |||
Shock (Operating) | 14.7 km/s2 { 1,500 G } ( 0.5 ms ) |
- Product image may represent a design model.
- Availability of the SED model line-up may vary by region.
- Definition of capacity: KIOXIA Corporation defines a megabyte (MB) as 1,000,000 bytes, a gigabyte (GB) as 1,000,000,000 bytes and a terabyte (TB) as 1,000,000,000,000 bytes. A computer operating system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 2^30 = 1,073,741,824 bytes and therefore shows less storage capacity. Available storage capacity (including examples of various media files) will vary based on file size, formatting, settings, software and operating system, and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
- MTTF (Mean Time to Failure) is not a guarantee or estimate of product life; it is a statistical value related to mean failure rates for a large number of products which may not accurately reflect actual operation. Actual operating life of the product may be different from the MTTF.
- TBW: Terabytes Written. The number of terabytes that may be written to the SSD for the specified lifetime.
- Read and write speed, tested on the state of "SLC cache=ON", may vary depending on the host device, read and write conditions, and file size.
- PCIe is a registered trademark of PCI-SIG.
- NVMe is a registered or unregistered mark of NVM Express, Inc. in the United States and other countries.
- Other company names, product names, and service names may be trademarks of third-party companies.
